Parameter Detail
Model AR155-II (Double Station)
Dimensions 155 × 155 × 126 mm
Material Hardened Steel + Aluminum Base
Jaw Width 130 mm (customizable)
Clamping Range 130 × 65 mm
Clamping Force 8‑10 kN @ 6‑7 bar
Weight 8.5 kg

ZERO POINT PRINCE – ZPP CNC
Your Partner in Precision Machining.
feature

Core Benefits – Quick & Clear

  • Double Station Design
    Two independent clamping stations let you load and machine two parts per cycle – double the throughput of single‑station vises. Perfect for high‑volume batch production.
  • Pneumatic Actuation
    Rapid clamping/unclamping with shop air (6‑7 bar) – no manual wrenching, consistent clamping force cycle after cycle. Ideal for automated cells and lights‑out machining.
  • Optimized Clamping Range
    130 mm jaw width (customizable) and 130×65 mm clamping range – handles a variety of medium‑to‑small components, from blocks to brackets and housings.
  • Rigid Hybrid Construction
    Hardened steel jaw ways and critical components + lightweight aluminum base – eliminates jaw lift and deformation under extreme clamping forces while keeping weight low (8.5 kg).
  • Compact Footprint
    155×155 mm square footprint, only 126 mm high – fits easily on crowded machine tables, 5‑axis trunnions, or pallet pools. Well‑designed structure avoids machining interference.
applicable scene

Key Use Cases

  • Automotive & Heavy Machinery – Load two small brackets, housings, or levers – machine both in one cycle. Double output without doubling machine time.
  • High‑Mix Production Cells – Pneumatic actuation allows integration with robotic load/unload systems – perfect for automated batch production.
  • Palletized Workflows – Mount on zero‑point pallets (pull studs – sold separately) for sub‑minute changeover of entire double‑station vises.

Double Your Throughput with Pneumatic Speed

The AR155‑II double station pneumatic vise combines twin‑station design, 8‑10 kN clamping force, and a compact hybrid build – faster cycles, more parts per hour, and zero compromise on rigidity.
