AP52-2304 Pneumatic Zero Point Clamping Unit – High Precision (230*230*30mm)

Large Square Pneumatic Clamping, Full 20 kN Locking Force

Automate Heavy, Large‑Format Pallets with One Compact Unit

Need pneumatic zero‑point clamping for oversized pallets or twin‑side fixture plates? The AP52‑2304 delivers 20 kN locking force @ 7 bar in a generous 230×230×30 mm hardened stainless steel body – only 30 mm high, with a large square footprint. Perfect for automated pallet pools, tombstone fixtures, or 5‑axis trunnions requiring maximum clamping area in minimal height.

Core Benefits – Quick & Clear

•
  Pneumatic Actuation
  Lock/unlock with shop air (7 bar). Seamless integration into robotic cells or lights‑out machining – no manual operation, consistent <0.005 mm repeatability.

•
  20 kN Locking Force @ 7 bar
  Powerful, reliable clamping for large pallets, heavy fixtures, or twin‑station workholding. Holds rigidly under heavy milling or high‑speed finishing.

•
  Large Square Footprint
  230×230 mm mounting area – ideal for single‑unit support of large pallets (up to 500 mm square). 10×M10 mounting holes ensure vibration‑free attachment.

•
  Ultra‑Low Profile
  Just 30 mm tall – preserves critical Z‑axis stroke on 5‑axis machines, gantries, or low‑clearance setups.
